Steel Pipes For Scaffolding System
Scaffold tube, also called scaffolding tube, is the main component of the scaffolding construction system. Scaffolding tube are widely used as a temporary structure to help workers craw and repair building in height. Also scaffolding tubes are frequently be used in formwork and shoring system.
The outside diameter is 48.3mm with thickness 3.2 or 4.0mm. There are different grade of scaffolding tube, such as S235, S355. Our factory has more than 15 years experience in Scaffolding tube, we can produce EN39, EN10219, BS1139 and JIS3444 standard tube. All are produced strictly according to the standard. Usually the surface is hot dipped galvanized with zinc coating above 210g/m2, which offers long term corrosion resistance.
1. Product Description
Steel Pipe for Scaffolding System
Pipe OD | 48.3mm |
Pipe Thickness | 1.6 - 4.75mm |
Length | 1- 6.4m |
Surface | Hot dipped Galvanized |
Standard | EN39/EN10219/BS1139/JIS3444 |
2. Production Process
We have our own QC team to inspect the steel pipe quality from raw metarial, in-line production and loading process.
We check the steel pipr quality from OD, thickness, surface and so on. All steel pipes are certificated with mill certificate.
3. Packing and Loading
1. Hexagonal package with steel strips for solid unloading
2. Waterproof plastic wrap package
3. Steel pallet package as per your request
4. Quality Control
